Product type：TFT LCD Module
Show contents：280x1424
Outline size(mm) ：38.2x182.47x11.5
Size of View Window(mm)：7.0
Display size(mm) ：7.0
Effective size(mm)：33.6x170.88
Product application：industrial control systems, handheld electronic devices,
Visual angle：IPS
Backlight type or brightness：700cd/m2
Connection PIN Number：FPC-30 pin
Interface mode：LVDS
Special instructions：IPS
Working temperature：-30~80℃
Power supply voltage：+3.3V
Elevate your central control systems with our cutting-edge 7.0-inch TFT LCD Display Module. Engineered for superior performance in demanding environments, this module is the ideal solution for applications requiring excellent readability, robust construction, and reliable signal transmission.
This 7.0-inch TFT LCD Display Module boasts a high-brightness IPS panel with 700 cd/m2, ensuring clear and vivid visuals even under direct sunlight or in bright indoor settings. With a resolution of 1424 x 280 pixels and a wide IPS viewing angle, critical information is displayed flawlessly from any perspective. The compact dimensions of 182.47 x 38.2 x 9.6 mm make it a perfect fit for sleek, modern dashboard and console designs.
A key feature of this 7.0-inch TFT LCD Display Module is its LVDS interface. This stable digital interface ensures high-speed, low-noise data transmission, delivering crisp image quality and exceptional reliability for your mission-critical control applications. Paired with a 30-pin FPC connector, the LVDS interface provides a robust connection that is built to last.
Built to withstand harsh conditions, this module offers an impressive operating temperature range from -30°C to 80°C and features 8KV ESD protection, guaranteeing stable operation in industrial settings. The 3.3V power supply further enhances its efficiency. Choose our versatile and durable 7.0-inch TFT LCD Display Module as the cornerstone of your next-generation control interface.
